Posted 4th Sep 2017

Our new STAR SR20J - Installed and running end of August.

The SR-20J provides high performance and flexibility with numerous tooling attachments to suit the main and sub-spindle platens. The high specification Fanuc 31iB control is packed with functions that ensure programming, setting and overall machine management is simple and undemanding.

A total of up to 30 cutting tools are available including 14 power-driven tools for cross drilling, milling, slotting and angular hole machining. The deep drilling stations allow holes up to 10mm diameter by 100mm deep to be machined on the main spindle.

The independent sub spindle has a fully programmable C axis. Polar co-ordinate control is also included as standard, allowing profiles such as hexagons and squares to be machined

• Standard machining diameter 20mm (22.2mm optional)
• Maximum Z1 stroke of 205mm in Swiss mode (Guide Bush)
• Main spindle speed 10,000 rpm, sub-spindle speed 8,000 rpm
• High specification F31iB control
• C-axis control on main and sub-spindles
• 4 Back-working power tools available
• 2 Modular (cartridge) stations on main platen
• Fully independent sub spindle for maximum overlapping
• Two independent deep hole drilling stations (main spindle)

https://www.stargb.com/star-products/sr-20j/
